D5300 Four Channel Thermocouple Input Module
$275.00
The D5300 four channel thermocouple input modules measure four different thermocouple types including J, K, T, E types. The thermocouple input modules provide an isolated 15-bit measurement, analog to digital conversion and a linearized data output scaled in user-selectable degrees C or F values. The scaled data is communicated using either RS-232 or RS-485.
The D5300 series thermocouple input modules can be mounted on a DIN-Rail using the MK-1 mounting kit.
Thermocouple Measurement Ranges:
J= -200 to +760 C
K= -150 to +1250 C
T= -200 to +400 C
E= -100 to +1000 C
Additional information
| Dimensions | 3.60 × 2.45 × 1.1 in |
|---|---|
| Specifications | • Thermocouple Types: J, K, T, E |
| Protocol | |
| Communications |
