D5200 4-20mA Current Input Module
$250.00
The D5200 four channel 4-20mA current input modules provide direct connection to four signals of the same input type with full scale input range of 0-25mA.
The 4-20mA input modules provide an isolated 15-bit measurement, analog to digital conversion and a linearized data output scaled into engineering units. The scaled data is communicated using either RS-232 or RS-485.
The D5200 series include user-selectable linear scaling of the ADC output data values to desired engineering units that match the application. For example, the D5200 can be rescaled for the 4-20mA values to be output as 0-100%. The user-selectable linear scaling applies to all four channels.
The D5200 four channel 4-20mA current input modules can be mounted on a DIN-rail using the MK-1 mounting kit.
Additional information
| Dimensions | 3.60 × 2.45 × 1.1 in |
|---|---|
| Specifications | • Range: 4-20mA (0-25mA full scale). |
| Communications |
