D1000M Series

$250.00 – $325.00

The D1000M series analog input modules are a complete family of data acquisition products that are well suited for applications based on personal computers, PLC’s or other supervisory computers that support the Modbus RTU serial protocol. The modules are ideal for creating or expanding distributed monitoring systems as they are small in size, mount on a DIN rail and operate on a wide power supply voltage input range.

The D1000M analog input modules measure DC voltages and current such as 4-20mA, thermocouples, RTD’s, thermistors, load cells and frequency. Each module provides an isolated 15-bit measurement, analog to digital conversion and a linearized data output. The data values are communicated to a host computer using the Modbus RTU serial protocol via an RS-232 or RS-485 serial port.

The D1000M series modules include discrete digital inputs and open-collector digital outputs. The digital inputs can be used to monitor contact status or switch closures. The digital outputs can be used to control solid-state relays or annunciators. The amount of digital I/O bits is model dependent, based on the sensor type and the number of sensor connections.

The D1701M and D1702M digital I/O modules contain seven discrete digital inputs and eight open-collector digital outputs for applications that require additional digital I/O capacity. The D1701M and D1702M communicate using the Modbus RTU serial protocol

Download Datasheet

Download Manual

Modbus Scaling Overview

Select options$250.00
Select options$250.00
Select options$325.00
Select options$325.00
Select options$250.00
Select options$325.00
Select options$250.00
Select options$275.00
Category: Tags: , , , , , , , , , , , , , , , ,

Additional information

Power

• Unregulated +10-30Vdc, 0.75W Max (D1500M, 2.0W Max.).
• Protected against power supply reversals

Communications

• RS-232 or RS-485 Serial Interface
• DGH ASCII or Modbus RTU Protocol
• Baud Rate: 300-115.2K
• Parity: Odd, Even, None
• User-Selectable Channel Address
• All settings stored in EEPROM

Software

The D1000M series remote I/O modules are compatible with all commercial software programs and OPC servers that support the Modbus RTU protocol. Commercials software programs from DreamReport, Wonderware, National Instruments Labview, Indusoft, DAQFactory and DASYLab all support the Modbus RTU protocol. OPC Servers from Kepware and MatrikonOPC support the Modbus RTU protocol.

Applications

• Process Monitoring and Control
• Remote datalogging to a host computer
• Product Testing
