- Measure DC voltages, 4-20mA current loops, thermocouples, RTD, thermistors, load cells, and frequency analog signals
- Isolated analog input
- 15-bit measurement resolution
- Discrete digital I/O bits for controlling solid state relays
- Modbus RTU serial protocol for RS-232 or RS-485
- Instant connectivity to data acquisition software programs
- Voltage Outputs
- Accuracy: 0.1% of full scale range max
- 12-bit output resolution
- 1000 conversions per second
- Settling time: 300uS typical (1 mS max.)
- Span tempco: +/-50ppm/degree C max
- Voltage output drive: 5mA max
- Three digital inputs
- Modbus RTU Serial Output
- RS-232 or RS-485
- Measure DC voltages, 4-20mA current loops, thermocouples, RTD, thermistors, load cells, and frequency analog signals
- Isolated analog input
- 15-bit measurement resolution
- Discrete digital I/O bits for controlling solid state relays
- Digital output bits can be configured as on/off alarms
- Modbus RTU serial protocol for RS-232 or RS-485
- 7 differential analog inputs measure DC voltages, 4-20mA current loops, thermocouples, & discrete digital I/O bits
- 15-bit measurement resolution
- Isolation between sensor & power grounds
- Direct connection to wide variety of sensors & annunciators
- User configurable using RS-485 Modbus RTU serial protocol
- Protocol provides instant connectivity to data acquisition software
- 7 differential analog inputs measure DC voltages, 4-20mA current loops, thermocouples, & discrete digital I/O bits
- 15-bit measurement resolution
- Isolation between sensor & power grounds
- Direct connection to wide variety of sensors & annunciators
- User configurable using RS-485 Modbus RTU serial protocol
- Protocol provides instant connectivity to data acquisition software
- 7 differential analog inputs measure DC voltages, 4-20mA current loops, thermocouples, & discrete digital I/O bits
- 16-bit measurement resolution
- Isolation between sensor & power grounds
- Direct connection to wide variety of sensors & annunciators
- USB Interface
- User-configurable using Modbus RTU Serial Protocol.
- Instant connectivity to data acquisition software
- Programmable analog input modules
- Measure DC voltages, 4-20mA current loops, load cells, and frequency signals
- Isolated analog input
- Scales output data in user-programmable engineering units
- Scale both linear and non-linear transfer functions
- Beneficial when data cannot be scaled in host computer
- Measure DC voltages, 4-20mA current loops, thermocouples, RTD, thermistors, load cells, and frequency analog signals
- Isolated analog input
- 15-bit measurement resolution
- Discrete digital I/O bits for controlling solid state relays
- Modbus RTU Serial Protocol using RS-485
- Instant connectivity to data acquisition software
